复杂循环路径下钢材弹塑性屈曲行为研究

王宇航; 余洁; 吴强

doi:10.6052/j.issn.1000-4750.2017.07.0525

复杂循环路径下钢材弹塑性屈曲行为研究

1.
重庆大学土木工程学院, 重庆 400045;
2.
重庆大学山地城镇建设与新技术教育部重点实验室, 重庆 400045;
3.
四川省建筑设计研究院, 成都 610000

基金项目: 国家重点研发计划项目（2016YFC0701201）；国家自然科学基金项目（51778085）；重庆市基础科学与前沿技术研究专项一般项目（cstc2017jcyjAX0238）

详细信息

作者简介:
余洁(1993-),女,重庆人,博士生,主要从事组合结构研究(E-mail:cquyujie@sina.com);吴强(1992-),男,重庆人,硕士生,主要从事钢结构耗能减震研究(E-mail:wuq92@outlook.com).

通讯作者:
王宇航(1985-),男,重庆人,研究员,博士,主要从事组合结构研究(E-mail:wangyuhang@cqu.edu.cn).

中图分类号: TU511.3+5
计量
- 文章访问数: 345
- HTML全文浏览量: 34
- PDF下载量: 112
出版历程
- 收稿日期: 2017-07-04
- 修回日期: 2017-09-04
- 刊出日期: 2018-07-24

ELASTIC-PLASTIC BUCKLING BEHAVIOR OF STEEL MATERIAL UNDER COMPLEX CYCLIC LOADING PATHS

1.
School of Civil Engineering, Chongqing University, Chongqing 400045, China;
2.
Key Laboratory of New Technology for Construction of Cities in Mountain Area(Chongqing University), Ministry of Education, Chongqing 400045, China;
3.
Sichuan Institute of Architectural Design and Research, Chengdu 610000, China

摘要

摘要: 复杂强震荷载作用下钢管混凝土柱中的钢管受压屈服后易发生局部屈曲，在杆系有限元模型中采用不考虑屈曲影响的钢材本构模型无法准确模拟钢结构构件的地震响应。为研究复杂循环荷载作用下钢材的屈曲行为，该文设计了强度等级分别为Q235和LYP160的30个钢材试件，并设计了多种复杂循环加载路径进行加载，获得了不同复杂循环荷载作用下钢材的弹塑性屈曲行为和应力-应变滞回关系。基于已有文献中的3种钢材循环本构模型：Légeron模型、GA模型和DM模型对试验结果进行对比分析和评价，结果表明：Légeron模型无法模拟钢材受压区服后的屈曲效应，GA模型中受压屈曲时的应力-应变规律与试验结果较为吻合，DM模型中受拉和受压卸载刚度与试验结果较为吻合。
- 钢材 /
- 弹塑性 /
- 屈曲 /
- 循环荷载 /
- 本构模型
Abstract: After compressive yielding, local buckling will occur on steel tubes in concrete-filled steel tubular column under complex seismic loading. In a bar-system finite element model (FE model), the seismic response of steel structure members cannot be effectively simulated by steel constitutive models without considering the influence of buckling. To study the buckling behavior of steel under complex cyclic loading, 30 steel specimens with strength grades Q235 and LYP160 were designed, and various complex cyclic loading paths were adopted to obtain the stress-strain hysteretic relation and elastic-plastic buckling behavior of steel under various complex cyclic loading. On the basis of three steel cyclic constitutive models in the literature:Légeron Model, GA Model and DM Model, the predicting results were compared and analyzed with the test results. It can be seen that Légeron Model fails to stimulate the buckling effect of post-compressive yielding steel, and in GA Model, the stress-strain properties of compressive buckling agree well with the experimental results. The unloading stiffness of tension and compression calculated by the DM Model agrees well with the test results.
- steel material /
- elastic-plastic /
- buckling /
- cyclic loading /
- constitutive model

HTML全文

参考文献(19)

[1]	蔡绍怀. 我国钢管混凝土结构技术的最新进展[J]. 土木工程学报, 1999, 32(4):16-26. Cai Shaohuai. The latest development of technology of concrete filled steel tubular structure in China[J]. China Civil Engineering Journal, 1999, 32(4):16-26. (in Chinese)
[2]	王凤, 王文达, 史艳莉. 钢管混凝土框架柱计算长度研究[J]. 工程力学, 2015, 32(1):168-175. Wang Feng, Wang Wenda, Shi Yanli. Research on the effective length of concrete-filed steel tube frame columns[J]. Engineering Mechanics, 2015, 32(1):168-175. (in Chinese)
[3]	Krawinkler H, Zohrei M. Cumulative damage in steel structures subjected to earthquake ground motions[J]. Computers & Structures, 1983, 16(1):531-541.
[4]	Castiglioni C A. Effects of the loading history on the local buckling behavior and failure mode of welded beam-to-column joints in moment-resisting steel frames[J]. Journal of Engineering Mechanics, 2005, 131(6):568-585.
[5]	郝际平. 钢结构在循环荷载作用下的局部屈曲、低周疲劳的试验与理论研究[D]. 西安:西安建筑科技大学, 1995. Hao Jiping. Test and theoretical research of local buckling and low-cycle fatigue of steel structure under cyclic loading[D]. Xi'an:Xi'an University of Architecture and Technology, 1995. (in Chinese)
[6]	Castiglioni C A, Pucinotti R. Failure criteria and cumulative damage models for steel components under cyclic loading[J]. Journal of Constructional Steel Research, 2009, 65(4):751-765.
[7]	陈勇, 董志峰, 张耀春. 方形薄壁钢管混凝土轴压短柱约束模型的建立[J]. 工程力学, 2012, 29(9):157-165. Chen Yong, Dong Zhifeng, Zhang Yaochun. The confined model on square stub column of concrete-filled thin-walled steel tube[J]. Engineering Mechanics, 2012, 29(9):157-165. (in Chinese)
[8]	王萌, 石永久, 王元清. 考虑累积损伤退化的钢材等效本构模型研究[J]. 建筑结构学报, 2013, 34(10):73-83. Wang Meng, Shi Yongjiu, Wang Yuanqing. Study on equivalent constitutive model of steel with cumulative degradation and damage[J]. Journal of Building Structures, 2013, 34(10):73-83. (in Chinese)
[9]	曹远军. 方钢管混凝土柱局部屈曲影响因素分析[D]. 重庆:重庆交通大学, 2010. Cao Yuanjun. Analysis of Influence factors to lvcal buckling of square concrete-filled steel tubular column[D]. Chongqing:Chongqing Jiaotong University, 2010(in Chinese)
[10]	Bayrak O, Mieses A M, Bae S. Inelastic buckling of reinforcing bars[J]. Journal of Structural Engineering, 2005, 131(2):314-321.
[11]	Gomes A, Appleton J. Nonlinear cyclic stress-strain relationship of reinforcing bars including buckling[J]. Engineering Structures, 1997, 19(10):822-826.
[12]	Hodge P G. The theory of piecewise linear isotropic plasticity. proceedings, colloquium on deformation and flow of solid[M]. Spain:Madrid:1955:147-169.
[13]	Esmaeily A, Xiao Y. Behavior of reinforced concrete columns under variable axial loads:Analysis[J]. ACI Structural Journal, 2005, 102(5):736-744.
[14]	Ramberg W, Osgood W R. Description of stress-strain curves by three parameters[J]. Technical Report Archive & Image Library, 1943(902).
[15]	Légeron F, Paultre P, Mazars J. Damage mechanics modeling of nonlinear seismic behavior of concrete structures[J]. Journal of Structural Engineering, 2005, 131(6):946-955.
[16]	Comite Euro-International du Beton (CEB). RC element under cyclic loading:State-of-the-art report[R]. Paris:Thomas Telford, 1996.
[17]	Dhakal R P, Maekawa K. Path-dependent cyclic stress-strain relationship of reinforcing bar including buckling[J]. Engineering Structures, 2002, 24(11):1383-1396.
[18]	Maekawa K, Dhakal R P. Modeling for postyield buckling of reinforcement[J]. Journal of Structural Engineering, 2002, 128(9):1139-1147.
[19]	聂建国, 王宇航. 基于ABAQUS的钢-混凝土组合结构纤维梁模型的开发及应用[J]. 工程力学, 2012, 29(1):70-80. Nie Jianguo, Wang Yuhang. Development and application of steel-concrete composite fiber beam model in ABAQUS platform[J]. Engineering Mechanics, 2012, 29(1):70-80. (in Chinese)
