JIANG Zi-qin, GUO Yan-lin, WANG Xiao-an, ZHANG Bo-hao. THEORETICAL STUDY ON BOLT DESIGN METHODS FOR DOUBLE RECTANGULAR TUBE ASSEMBLED BUCKLING-RESTRAINED BRACE[J]. Engineering Mechanics, 2016, 33(3): 55-64. DOI: 10.6052/j.issn.1000-4750.2014.09.0775
Citation: JIANG Zi-qin, GUO Yan-lin, WANG Xiao-an, ZHANG Bo-hao. THEORETICAL STUDY ON BOLT DESIGN METHODS FOR DOUBLE RECTANGULAR TUBE ASSEMBLED BUCKLING-RESTRAINED BRACE[J]. Engineering Mechanics, 2016, 33(3): 55-64. DOI: 10.6052/j.issn.1000-4750.2014.09.0775
shu

THEORETICAL STUDY ON BOLT DESIGN METHODS FOR DOUBLE RECTANGULAR TUBE ASSEMBLED BUCKLING-RESTRAINED BRACE

  • 1.

    Department of Civil Engineering, Tsinghua University, Beijing 100084, China;

  • 2.

    Shanghai Construction Group Co., Ltd., Shanghai 200080, China

More Information
  • Received Date: September 15, 2014
  • Revised Date: March 03, 2015
    Graphical Abstract
    • Abstract
  • The external restraining members of assembled buckling-restrained braces(ABRB) are assembled by high strength bolts, and the layout and dimension of the bolts are closely related to how efficient they are when an external member restrains the lateral deformation of a core member. Given such facts, and based on the studies of the restraining stiffness and design method of external restraining members for a double rectangular tube ABRB, this study focuses on the internal force of the mid-span bolt considering the effects of the bolt arrangement in an external member, the core wavelength of core multi-wave deformation, and the prying force resulting from the local deformation of plates of the external member. Besides, the calculation formula of internal forces and the local strengthening recommendation of end-bolts are also put forward. As a result, the design method for the bolts applied in a double rectangular tube ABRB has been improved.
    • FullText(HTML)
    • References (14)
  • [1]
    郭彦林, 江磊鑫. 型钢组合装配式防屈曲支撑性能及设计方法研究[J]. 建筑结构, 2010, 40(1):30-37. Guo Yanlin, Jiang Leixin. Behavior and application of buckling-restrained braces assembled with section steels[J]. Building Structure, 2010, 40(1):30-37.(in Chinese).
    [2]
    Zhao J, Wu B, Ou J. A novel type of angle steel buckling-restrained brace:Cyclic behavior and failure mechanism[J]. Earthquake Engineering & Structural Dynamics, 2011, 40(10):1083-1102.
    [3]
    Chou C, Chen S. Subassemblage tests and finite element analyses of sandwiched buckling-restrained braces[J]. Engineering Structures, 2010, 32(8):2108-2121.
    [4]
    Wang C, Usami T, Funayama J, et al. Low-cycle fatigue testing of extruded aluminum alloy buckling-restrained braces[J]. Engineering Structures, 2013, 46(9):294-301.
    [5]
    Usami T, Wang C L, Funayama J. Developing high-performance aluminum alloy buckling-restrained braces based on series of low-cycle fatigue tests[J]. Earthquake Engineering & Structural Dynamics, 2012, 41(4):643-661.
    [6]
    Hoveidae N, Rafezy B. Overall buckling behavior of all-steel buckling restrained braces[J]. Journal of Constructional Steel Research, 2012, 79(12):151-158.
    [7]
    郭彦林,王小安. 一种四角钢组合约束型防屈曲支撑的外围约束比取值研究[J]. 工程力学, 2013, 34(10):35-45. Guo Yanlin, Wang Xiaoan. Study on the restrain ratio of a four-angle assembled steel buckling-restrained brace[J]. Engineering Mechanics, 2013, 34(10):35-45.(in Chinese)
    [8]
    郭彦林, 姜子钦, 王小安, 等. 双矩管装配式防屈曲支撑约束刚度取值研究[J]. 工程力学, 2015, 32(4):22-32. Guo Yanlin, Jiang Ziqin, Wang Xiao'an, et al. Study on restraining stiffness of double rectangular tube assembled buckling-restrained brace[J]. Engineering Mechanics, 2015, 32(4):22-32.(in Chinese)
    [9]
    姜子钦, 郭彦林, 张博浩, 等. 双矩管装配式防屈曲支撑设计理论研究[J]. 工程力学, 2015, 32(6):41-51, 61. Jiang Ziqin, Guo Yanlin, Zhang Bohao, et al. Theoretical study on design methods for double rectangular tube assembled buckling-restrained brace[J]. Engineering Mechanics, 2015, 32(6):41-51, 61.(in Chinese)
    [10]
    郭彦林, 王小安. 一种双矩管对扣装配式防屈曲支撑构件[P]. 中国:201020574017.5, 2010-10-15. Guo Yanlin, Wang Xiao'an. A double rectangle tube assembled buckling restrained brace[P]. China:201020574017.5, 2010-10-15.(in Chinese)
    [11]
    龙驭球, 包世华. 结构力学(I)[M]. 北京:高等教育出版社, 2006:318-325. Long Yuqiu, Bao Shihua. Structural mechanics(I)[M]. Beijing:Higher Education Press, 2006:318-325.(in Chinese)
    [12]
    包世华. 新编高层建筑结构[M]. 北京:中国水利水电出版社, 2005:110-131. Bao Shihua. Tall building structures[M]. Beijing:China Water Power Press, 2005:110-131.(in Chinese)
    [13]
    GB50017-2003, 钢结构设计规范[S]. 北京:中国计划出版社, 2003. GB50017-2003, Code for design of steel structures[S]. Beijing:China Planning Press, 2003.(in Chinese)
    [14]
    陈绍蕃. 门式刚架端板螺栓连接的强度和刚度[J]. 钢结构, 2000, 15(1):6-11. Chen Shaofan. The strength and stiffness of bolted end-plate connection in portal frames[J]. Steel Construction, 2000, 15(1):6-11.(in Chinese)
